MC HCF-SG (Smartground)® Steel Armor THHN/THWN-2 Inners

Features

  • Sizes 12 AWG - 10 AWG
  • Permitted for 600-volt applications
  • Removable SmartColorID® label
  • Available in aluminum armor
  • Suitable for dry locations
  • Permitted for use in environmental air-handling spaces
  • RoHS compliant
  • UL Listed E-301130

Description

Encore's Metal Clad Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry. All conductors are individually wrapped with flame retardant colored protective paper with print legend and cabled together to form the cable core. Includes green ground same size as circuit conductors. The bare aluminum grounding/bonding conductor is located outside the paper wrap and is cabled with the insulated conductors and in constant contact with sheathing. Interlocked steel armor is applied over the entire assembly.
