AC Aluminum Armor THHN/THWN-2 Inners

Features

  • Sizes 14 AWG - 2 AWG
  • Permitted for 600-volt applications
  • Removable SmartColorID® label
  • Available in steel armor
  • Suitable for dry locations
  • Permitted for use in environmental air-handling spaces
  • RoHS compliant
  • UL Listed E-301130

Description

Encore’s Armored Cable is constructed with soft-drawn copper, Type THHN conductors. Each insulated conductor is individually wrapped with a moisture-resistant paper covering which has flame retardant properties. These conductors, are cabled together to form the cable core. A 16 AWG solid aluminum bond wire is placed longitudinally underneath the armor and remains in contact with the armor throughout the entire length. Interlocked aluminum armor is applied over the entire assembly.
